| Specifications | |
|---|---|
| ✓ Engine | H4E4ED95/3 |
| ✓ Emission | Euro IV |
| ✓ Type | Diesel, Direct injection, Common rail, Turbo charged with intercooler and i-EGR |
| ✓ No. of Cylinders | 4 in-line |
| ✓ Displacement | 3830 cc |
| ✓ Maximum Output | 130 HP @ 2400 rpm |
| ✓ Maximum Torque | 450 Nm @ 1250–2000 rpm |
| ✓ Clutch | Single dry plate type of 330mm diameter |
| ✓ Transmission Type | 6 Forward, 1 Reverse (FGR – 6.93) |
| ✓ Gear Box | ZF S6-36 Overdrive |
| ✓ Drive | Manual |
| ✓ Front Axle | Forged ‘I’ section, Reverse Elliot |
| ✓ Rear Axle | Fully floating single speed hypoid (RAR- 5.57) |
| ✓ Front & Rear Suspension | Semi elliptic multi-leaf springs with double acting shock absorbers |
| ✓ Brakes | Full air S-Cam Dual circuit |
| ✓ Parking Brakes | Spring actuated pneumatic on rear wheels |
| ✓ Steering | Hydraulic power assisted |
| ✓ Tilt | Standard |
