Engine
|
HA6ETI3UN |
|
✓
Emission
|
Euro III |
|
✓
Type
|
Diesel Direct Injection, Turbo charged with intercooler |
|
✓
No. of Cylinders
|
6 in-line |
|
✓
Displacement
|
5759 cc |
|
✓
Maximum Output
|
180 HP @ 2400 rpm |
|
✓
Maximum Torque
|
660 Nm @ 1500 rpm |
|
✓
Clutch
|
Hydraulic air assisted single dry plate, 380 mm diameter |
|
✓
Transmission Type
|
6 Forward, 1 Reverse (FGR – 6.93) |
|
✓
Gear Box
|
ZF S6-36 Overdrive |
|
✓
Front Axle
|
Heavy-duty A48 axle, Reverse Elliot, ‘I’ section |
|
✓
Rear Axle
|
Fully floating hypoid |
|
✓
Front Suspension
|
Parabolic leaf springs with double acting shock absorbers and anti-roll bar |
|
✓
Rear Suspension
|
Multi-leaf springs with double acting shock absorbers |
|
✓
Brakes
|
Full air S-Cam dual circuit |
|
✓
Parking Brakes
|
Spring actuated pneumatic on rear wheels with exhaust brake |
|
✓
Steering
|
Hydraulic power assisted |
|
✓
Tilt
|
Standard |
|
✓
Electrical System
|
24 V |
|
✓
Battery
|
110 Amp (2 × 12 V) |
|
✓
Alternator
|
85 Amps |
|
✓
Rim Size
|
245/70R19.5 |
|
✓
Tyre Type
|
Tubeless |
|
✓
Fuel Tank
|
208 L capacity with tank lock system |
|
✓
Wheelbase
|
1900 |
|
✓
Overall Width
|
2200 |
|
✓
Overall Length
|
8765 |
|
✓
Min Ground Clearance
|
260 mm |
|
✓
Turning Circle Diameter
|
18850 (TCD) |
|
✓
Rear Overhang
|
2600 |
|
✓
Seating Arrangement
|
3 × 2 with standard seat belt |
|
✓
GVW
|
12,000 kg |
